Products Description
1. Enhaced full line compatibility:controlled by micro-computer and anti-dust technology,this machine can be used for tablets(including irregular shape of tablets),capsules,soft capsules(including irregular shape of tablets,transparent or colorful gels),pellets and most other kinds of medicines and tabloids.
2. No blockage:Special designed hopper mouth,to prevent the drug blockage,even bottle with small mouth can be quickly filled.
3. No harm for materials:feeding and output are stable and averagrly,will do no harm on materials.Filling accuracy is guaranteed.
4. Detection function:machine will not count without detecting bottles' availability ,and will automatically reject abnormal filled bottles,and a certain degree broken of crushed tablets reject,self -diagnose,and alarm control system.
5. Anti-dust:Specially designed high anti-dust sensor technology,to ensure the machine running normally under heavy dust condition.
Good compatibility: tablets (including special-shaped tablets), capsules, soft capsules (transparent, opaque), pills and other solid preparations or solid particles can be counted and bottled.
Main features:
1. Three-stage vibrators:With 8-channel vibration, materials are distributed more evenly.
2. Reliable operation:It runs stably and smoothly with low noise.
3. High dust resistance:It adopts unique anti-dust photoelectric sensor.
4. Accurate counting:Due to photoelectric sensor detection and imported large PLC counting, bottle-filling error meets the international standard.
Main Technical Data | ||||
Model | LTEC-12 | LTEC-16 | LTEC-24 | LTEC-32 |
Slide wheel | 12 Channels | 16 Channels | 24 Channels | 32 Channels |
Size of Object | Tablet: φ5-12mm Capsule: 00#-5# all kinds of soft capsule | |||
Size of bottles | 20-300ml | |||
The diameter for bottles mouth | 20-80mm | |||
Output | 4,000pcs/min | 6,000pcs/min | 8,000pcs/min | 10,000pcs/min |
Capacity | 40bottles/min | 60bottles/min | 80bottle/min | 100bottles/min |
Power | 0.9KW | 0.9KW | 1.35KW | 1.35KW |
Power supply | 220V 60HZ | |||
Air pressure | 6kgs/c | |||
Overall dimensions(mm) | 1700×1700×1900 | 2000×1700×1900 | 2800×1700×1900 | 3200×1700×1900 |
